Citroën ë-C4 – 100% ëlectric : Citroën ë-C4 – 100% ëlectric: CHARGING AT HOME
The battery can be charged at home, work or at a public charging station. 3 types of charging are possible
The different types of charging :
● Standard domestic socket* (1.8kW): Charges in less than 9 hours for 100km
*cable available as standard or as an accessory, dependent on version. Not recommended for regular charging.
● Reinforced socket (3.7kW max): Charges in less than 4h 30 minutes for 100kw
● 7.4kW single-phase wall box *: Full charge in 7h 30 minutes
*cable available as standard or as an accessory, dependent on version.
● 11kW three-phase wall box *:Full charge takes 5 hours
*cable available as standard or as an accessory, dependent on version. Optional 11kW on-board charger and three-phase power supply required; check if this type of charging is available to you before ordering
To charge, your vehicle must be stationary with the handbrake on and the motor switched off. Locate the charging cable, available in the dedicated storage space in the boot, open the electric charging port located at the rear left-hand side:
● White LED: Welcome mode. Connect the charging cable to your vehicle
● Flashing green LED: Battery charging in process.The charging cable locks in place when charging begins.
● Solid green LED: Charging is complete.
● Once the charging has finished, unlock the vehicle to be able to disconnect the cable. If the vehicle was unlocked during charging. Lock and then unlock to disconnect.
Public charging station information: All standard public charging stations can be used with the charging cable supplied with the vehicle. Please note that rapid chargers are always equipped with their own built-in cable
Scheduled charging: To benefit from off-peak electricity rates*, you can schedule charging to take place during off-peak hours.
*if available with your electricity provider.
Press the electric page direct access button and then press the ‘charge’ tab, then set the desired charging start time. To confirm programming, press the scheduled charge button located in the electric port.
● Solid blue LED: Scheduled charging activated
